INMARCO STYLE 101
INMARCO STYLE 101 is a special packing manufactured from carbon fibre yarn. The packing is thoroughly impregnated with naturally cured graphite based intherm dispersion to act as blocking agent. The interbraid construction and the blocking agent prevents body leakage of any gaseous or liquid material. To prevent galvanic corrosion on the steam, molybdenum based metal corrosion inhibitor also is incorporated in the packing.
Advantages:
- Adequate lubrication for Low friction runs
- No embrittlement or abrasion to metallic parent equipment.
- Strong but pliant without brittleness.
- Excellent heat dissipation for cooler shaft runs without wear to packing volume to ensure excellent sealing service.
Typical Applications:
Pumps, Valves, Agitators, Dryers, Mixers, Soot blowers, etc.
Service Media:
Acids, Alkalis, Solvent, Organic chemicals, Gases, Steam, Thermic fluids, etc.
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (ÂoC) | -200 to +650 | ||
| PRESSURE (BAR) | 200 | 300 | 200 |
| VELOCITY (m/s) | 25 | 25 | __ |
| SIZE | 3mm2 to 50mm2 | ||
INMARCO STYLE 102
INMARCO STYLE 102 interbraided from goretex expanded PTFE + graphite fiber, which is a single molecular combination of PTFE and graphite, offers excellent inertia to chemical attack and enhance heat conduction, helping to reduce friction.INMARCO STYLE 102 graphite entrapment in expanded PTFE matrixes provides excellent lubrication & resistance to hardening unlike the conventional PTFE packings. The sealing performance is the best among any other PTFE graphite pckings.
Advantages:
- Easy to cut and fit.
- Very low friction and high heat conduction.
- Low thermal expansion.
- No static charge builds up.
- Easy on shafts and help cool runs.
Typical Applications:
Pumps, Valves, Reactors, Agitators, etc
Service Media:
Acids, Alkalis, Organic Chemicals, Hot water, DM water, Hydrocarbons, Thermic fluids, etc
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (ÂoC) | -240 to +300 | ||
| PRESSURE (BAR) | 150 | 125 | 300 |
| VELOCITY (m/s) | 25 | 10 | __ |
| SIZE | 3mmÂ2 to 35mmÂ2 | ||
INMARCO STYLE 103
INMARCO STYLE 103 is manufactured from a premium graphite PTFE yarn impregnated with proprietary in blend dispersion in high density braiding. INMARCO STYLE 103 is premium graphite PTFE yarns ensure excellent self-lubrication to control frictional heat and to eliminate shaft galling, so common in other PTFE graphite yarns. Moreover, this results in overall inert packing. INMARCO STYLE 103 graphite in in blend ensures excellent heat dissipation without hardening thus limiting shaft wear.
Typical Applications:
Equipment’s like mixers, agitators, autoclaves, reactor vessels etc., pain stocks, centrifugal/rotary pumps, pumps with damaged shafts and stuffing boxes, valves with grooved stem and pitted glands, flange grooves.
Service Media:
Acids, Alkalis, Solvents, Resins, Effluents, etc.
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (oC) | -240 to +300 | ||
| PRESSURE (BAR) | 120 | 100 | 300 |
| VELOCITY (m/s) | 25 | 10 | __ |
| SIZE | 3mm2 to 35mm2 | ||
INMARCO STYLE 105
INMARCO STYLE 105 is a dense braided combination gland packing having aramid yarn corners with PTFE yarn faces with highly resilient and high tensile core of aramid fibre. The aramid yarn is lubricated with highly anti-frictional fluoropolymer dispersions and break-in lubricant, while the PTFE faces are lubricated with high temperature resisting inert lubricant.INMARCO STYLE 105 offers excellent strength coupled with dimensional stability in service. Strong aramid fibre avoids corner failures in reciprocating plunger pump. The PTFE fibre ensures low friction, cool shaft runs eliminating wear and tear to plunger & valve stems. The strong aramid fiber core provides extremely high pressure resistance.
Typical Applications:
Centrifugal reciprocating & plunger pumps, Valves, Agitators, Extruders, Mixers, Reactors etc.
Advantages:
- Dense construction & excellent seal ability.
- High pressure & compatibility.
- Extremely durable packing for ammonia and carbamate solution.
- Can be used as lip seals
- Wide chemical & abrasion resistance & high penetration
| Properties | |||
|---|---|---|---|
| pH | 0-13 | ||
| TEMPERATURE (oC) | -200 to +280 | ||
| PRESSURE (BAR) | 150 | 500 | 500 |
| VELOCITY (m/s) | 25 | 20 | __ |
| SIZE | 4mm2 to 35mm2 | ||
INMARCO STYLE 117
INMARCO STYLE 117 Graphited PTFE Fiber packing with carbonaceous aramid core and corners.
Advantages:
- High compressive & tensile strengths ensure effective sealing.
- Due to the interim sealer & the carbon fibers, the packing exhibits superior heat dissipation.
- The Graphited PTFE fibers reduce the packing & the shaft wear.
- Universal replacement to Asbestos in arduous operating conditions.
Typical Applications:
Equipment relevant to paper water treatment, power, chemical, distillery & petrol chemical industries. Screw pumps handling powdered slurries. Fomenters, Reactors, Mixers and Agitators. Application involving slurry, sand, gritty media and as a ‘Bull Ring’.
| Properties | |||
|---|---|---|---|
| pH | 0-13 | ||
| TEMPERATURE (oC) | -240 to +280 | ||
| PRESSURE (BAR) | 150 | 500 | 375 |
| VELOCITY (m/s) | 25 | 3 | __ |
| SIZE | 3mm2 to 35mm2 | ||
INMARCO STYLE 123
INMARCO STYLE 123 Ceramic Fibre Rope is diagonally braided or over braided or around a bulk ceramic rope core, the fibers are either E-Glass reinforced or Stainless Steel wire reinforced and can withstand temperature up to 1260°C.
INMARCO STYLE 123 is available with special chemical treatment which will not only make the product flame
proof/fire retardant but also will increase the temperature resistance up to 1400°C.
INMARCO STYLE 123 conforms to ISO14000 norms and is environmentally friendly, non-toxic and non health hazardous. Ceramic products conform to physical parameter including dimensions to IS 14656. There are no specific standards for ceramic fibre rope but are generally covered under ASTM C892
Advantages:
- Nontoxic, non-health hazardous and environmental friendly.
- Longer life due to no less of strength at optimum working temperature.
- High thermal insulation properties ensures friendly working atmosphere.
- Noncombustible and electrically nonconductive (nonmetallic).
- Increase safety of plant personnel and improves productivity.
Typical Applications:
Superior replacement of asbestos static door seals in boilers/ovens/reformers/heat exchangers/radiant tube packing core/heat treatment furnaces/thermocouple tubes/dummy bar seals/insulation of pile lines/exhaust and pipe line expansion joints/high temperature valve glands in air, fuel and gas.
Service Media:
Superior heated and saturated steam, non-oxidizing liquids and gases, hot blast, alumina in power and molten form, dyes and chemicals, mild acid and alkalis
| Properties | Unit | Value (Style 123/123-s) |
|---|---|---|
| Composition - A1203 | % | 42-46 |
| SiO2 | % | 52-55 |
| Fe2 O3 | % | 1 |
| Ti O2 | __ | Traces |
| Max. Working Temperature | oC | 1260 |
| Melting Point | oC | 1760 |
| Effective under pH range | pH | 2-12 |
| Leachable Chloride content | % | <100 |
| Loss on Ignition (@average of 1200oC) | % | 15max |
| Linear Shrinkage (@average 1200°C) | % | 3 |
| Average Density | Kg/m3 | 600-800 |
| Thickness | mm | 3.0 to 90 cross section (round/square) 10 |
| Standard Length | 100 (3-10mm), 50(12-25mm), 20(30-50mm) & 10(60-90mm) | |
INMARCO STYLE 160
INMARCO STYLE 160 an excellent hybrid combination non-asbestos packing rope for static sealing applications. The packing has a central core of inorganic bulk fibre and outer braided jacket with gas & heat resistant inorganic filament yarn. The packing is a combination of extremely high mechanical strength and resiliency which is most important in sealing application. INMARCO STYLE 160 does not cause any itching sensation on human skin as caused by conventional ceramic yarn/packing. INMARCO STYLE 160 is a extremely very good packing for Coke oven door sealing, Caulking, Furnace door sealing etc because of extremely good resiliency and also extremely low loss on ignition.
Advantages:
- Extremely high thermal and electrical insulating properties.
- No embrittlement or abrasion
- Do not cause itching sensation on skin.
- Negligible volume loss during operation due to extremely low loss on ignition.
- Negligible volume loss leads to longer leakage-free operational life.
Typical Applications:
Hot blast valve, Furnace door sealing, Coke oven door sealing & caulking, Mill door sealing, Pouring ladle, etc.
Service Media:
Super-heated & saturated steam, Non-oxidizing liquids and gases, Hot blast, Molten alumina, Flue gas, etc
| Properties | Value | ||
|---|---|---|---|
| TEMPERATURE (oC) | -240 to +280 | ||
| THERMAL CONDUCTIVITY | 0.14 WMK (@average 650oC) | ||
| LOSS ON IGNITION | 5% max. @850oC | ||
| SIZE | 12mm sq.dia _ 100mm sq/dia | ||
INMARCO STYLE 501
INMARCO STYLE 501 is a specially developed hybrid combination packing of non metallic expanded pure graphite yarn reinforced with high structural carbon filament at four corners. The packing is impregnated with proprietary THERMOLUBE graphite based dispersion and also INORGANIC PASSIVE CORROSION INHIBITOR. This passive corrosion inhibitor safeguards parent equipment from galvanic corrosion and also reduction of LOSS ON IGNITION.INMARCO STYLE 501 is a combination of softness of expanded pure graphite and toughness of carbon fiber yarn. The packing is highly chemical resistant and very good thermal conductor. This can be used both in dynamic and static application.
Advantages:
- Excellent dry run capabilities and hence reduce continuous water flashing.
- Incorporation of corrosion inhibitor prevents corrosion and pitting on parent equipment.
- THERMOLUBE dispersion act as a blocking agent
- The packing adapts to worn out surface and pitting with smooth running.
- Dissipates heat without chemical hardening.
Typical Applications:
Pumps, Valves, Autoclaves, Converters, Mixers, Reactors, etc.
Service Media:
Hydrocarbon, Steam, FCC catalyst & bottom slurry, Hypo, Fuel oil, Lube oil, Thermic fluid, Hydrogent sulphide, Liquid Sulphur, Sulphur Dioxide, Sulphur trioxide, Acids & Alkalis, Boiler feed water, Gasoline, Abrasive media like slurry, Fly ash water, Sea water, etc.
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (ÂoC) | -200 to +650 (2750ÂoC in non oxidizing media) | ||
| PRESSURE (BAR) | 150 | 300 | 350 |
| VELOCITY (m/s) | 25 | 20 | __ |
| SIZE | 6mmÂ2 to 50mmÂ2 | ||
INMARCO STYLE 504IV
INMARCO STYLE 504IV is an improved version duplex braided packing manufactured from Expanded PTFE intimately entrapped with high quality Graphite into the porous of Expanded PTFE resin. The PTFE Graphite yarn is made in single molecular structure. This is a dense packing having high Degree of Resiliency and chemical properties. Presence of Graphite enables the packing dissipate heat accurately leading to longer life of the packing.Style 504IV is highly ant frictional and hence able to safeguard Shaft / Sleeves from Wear / Erosion. This Packing is having excellent resistance to almost all known chemicals and is compatible to wide range of industrial media and is only affected by strong Oxidizers, Molten Alkali Metal and Fluorine compounds.Style 504IV is dimensionally stable and requires minimum Gland loading to effect perfect seal. This is also compatible to very high peripheral speed with extremely low leakage rate.
Typical Applications:
Centrifugal & Reciprocating pumps, Valves, Large diameter shafts, Reactor vessels, Agitators, Mixers, Autoclaves, etc
Service Media:
Acids & Alkalis of any concentration, Solvents, Hydrocarbons, Phosphoric acids, Raw water, DM water, Condensate, Cooling water, etc
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (ÂoC) | -200 to +300 | ||
| PRESSURE (BAR) | 100 | 200 | 350 |
| VELOCITY (m/s) | 25 | 10 | __ |
| SIZE | 3mm2 to 50mm2 | ||
INMARCO STYLE 508
INMARCO STYLE 508 is a Pure PTFE Fiber yarn duplex braided packing having incorporation of special proprietary inlube break-in lubricant & also incorporating PTFE suspensoid. The break-in-lubricant ensures extra lubrication during the complete operational life and dispersion acts as blocking agent as well as antifrictional additives.INMARCO STYLE 508 is non toxic and inert in nature, hence ensures safety and purity of the fluid media. It is dimensionally stable and ensures trouble free operation reducing maintenance cost.INMARCO STYLE 508 is suitable for dynamic as well as static application. As it dimensionally stable it ensures leakage free operational life for a longer period.
Typical Applications:
Pumps, Valves, Mixers, Reactors, Agitators, Dryers, Air compressors, etc.
Service Media:
Acids & Alkalis of any concentration, Solvents, Organic/Inorganic Chemicals, Petrochemicals, Dyestuffs, Paints, Synthetic Resins, etc.
| Properties | |||
|---|---|---|---|
| pH | 0-14 | ||
| TEMPERATURE (ÂoC) | -240 to +290 | ||
| PRESSURE (BAR) | 150 | 350 | 300 |
| VELOCITY (m/s) | 28 | 24 | __ |
| SIZE | 3mm2 to 50mm2 | ||
